Sending email with inline image with Xojo 2024r2 Desktop

Gabriele_Marchionni · July 5, 2024, 12:02pm

I’m using Xojo 2024r2 Desktop, with components EmailMessage e SMTPSecureSocket.
I’m trying to send an email in html with an inline image. Reading the posts on the forum I’m trying to solve the problem. But without success.
I also attach a sample project ( Download )

I try to insert a base64 inline image into the HTML code when I send the EmailMessage with SMTPSecureSocket, but the image cannot be seen.

This is the source received via email:

Mime-Version: 1.0
Content-transfer-encoding: 8bit
Content-Type: multipart/alternative; boundary="cpyxa3yvte8v"
X-CMAE-Score: 0
X-CMAE-Analysis: v=2.4 cv=D/WMKeRj c=1 sm=1 tr=0 ts=6687d802 a=Z27dpK4bOWhRHOCpLmIrNQ==:117 a=Z27dpK4bOWhRHOCpLmIrNQ==:17 a=HpEJnUlJZJkA:10 a=5KLPUuaC_9wA:10 a=g8TUdU_LZmEA:10 a=4oh2u1aVau_54mSFC8MA:9 a=NLMQV5p5AAAA:8 a=V5I0dzQLXKsO3V3TnZcA:9 a=_W_S_7VecoQA:10 a=aWTw2_BOBUSB0_-UnHUG:22

--cpyxa3yvte8v
Content-type: text/plain;

Title 1 of my email
Paragraph in the body
This is a test email. Let's try inserting html code with bold and also a link.


--cpyxa3yvte8v
Content-type: text/html;

<!DOCTYPE html>
<html>
<head>
<title>Test email message with xojo</title>
<meta charset="utf-8">
</head>
<body>
<h1>Title 1 of my email</h1>
<p>Paragraph in the body</p>
<p>This is a test email. Let's try inserting html code with <strong>bold</strong> and also a <a href="https://xojo.com">link</a>.</p>
<p>
</p>
</body>
</html>


--cpyxa3yvte8v--

The email source appears correct, but the image is not visible.
If I copy and paste the HTML part into a file and open it with the browser the image appears.

I also tried using the CID and attaching the image file trying to change the Source of the message object. If I do this I don’t know why but EmailMessage always changes the boundary, and therefore what I insert has a different boundary from that of the email.

--cpyxa3yvte8v
Content-Type: image/png; name="img_inline.png"
Content-Transfer-Encoding: base64
Content-ID: <part1.02080004.04000407@sample.com>
Content-Disposition: inline; filename="img_inline.png"

iVBORw0KGgoAAAANSUhEUgAAABAAAA........

Has anyone faced, and solved, the same problem with inline images?

Thanks,
Gabriel

Beatrix_Willius · July 5, 2024, 12:53pm

The CID way is the usual way to send inline images. But the html is correct and the email shows up in my inbox correctly for Mail:

I just hope that this isn’t production code.

Gabriele_Marchionni · July 5, 2024, 1:03pm

It didn’t seem to work because I always checked with Gmail. I see it in Outlook. In Gmail, however, no.

Gmail:

Outlook:

Beatrix_Willius · July 5, 2024, 1:10pm

Yup, the Goggle ain’t happy with the little icon:

Please goggle if this is a security issue.

Gabriele_Marchionni · July 5, 2024, 1:16pm

From Google…

Question: Why don’t Base64 images appear in Gmail?
Answer: Gmail blocks Base64 images due to security policies intended to protect users from potentially harmful content.

This thing limits a lot. Pretty much everyone with a gmail email won’t see the images. Therefore millions of people.

If only I could send images with the CID method I would have solved the problem. But xojo doesn’t allow it. Or I wasn’t good at finding the method to do it.

Beatrix_Willius · July 5, 2024, 1:22pm

I’ll do some checking on the CID next because this should work fine. Alternatively, there are the Chilkat plugin or Curl.

RomanV · July 5, 2024, 1:28pm

Hi,
If you want to do this without plugins, this is the way to go.

http://webcustomcontrols.com/open-source/emails-with-embedded-images-using-realbasic/

Cheers
Román

Gabriele_Marchionni · July 5, 2024, 2:17pm


TimStreater · July 5, 2024, 3:42pm

Yes, and it works. My email client (written in Xojo) sends and receives mails with and without images using the cid: method, no problems. I’m not using any Xojo email classes.

TimStreater · July 5, 2024, 3:54pm

You have to put:

<img src="cid:part1.02080004.04000407@sample.com"> in the body of the mail, where you want the image to appear. That is the way to match the body part with the image, to the body part with the html of the mail.

If you receive such a mail, you have to decode and store the image part, and, when displaying the mail, change the body so that instead of having:

<img src="cid:part1.02080004.04000407@sample.com">

you have:

<img src="/path/to/local/image.png">

I’ve had to change how this worked more than once because of annoying limitations imposed by the HTMLViewer on one desktop platform or another.

Marius_Dieter_Noetzel · July 5, 2024, 4:29pm

Here, it is quick and dirty with native xojo:

SendMailSocket = New SMTP
SendMailSocket.Address = "your.smtp.com" // your SMTP email server
SendMailSocket.Port = 587 // Check your server for the property port # to use
SendMailSocket.SSLConnectionType = SMTPSecureSocket.SSLConnectionTypes.TLSv1
SendMailSocket.Username = "YourEmailUsername"
SendMailSocket.Password = "YourEmailPassword"

// Create the actual email message
Var mail As New EmailMessage
mail.FromAddress = "sender@domain.com"
mail.Subject = "////> Test Email from Xojo"
mail.BodyPlainText = "Hello, World!"
mail.Headers.AddHeader("X-Mailer", "Xojo SMTP Example") // Sample header
mail.AddRecipient("recipient@domain.com")

Dim att As New EmailAttachment
Dim f As New folderitem("/path/to/file.png")
att.LoadFromFile(f)
att.MIMEType = "image/png"
mail.Attachments.Add(att)

Dim src As String = mail.Source

Dim cid As String = "myCoolImage"
src = src.Replace("Content-disposition: attachment; filename=""" + f.Name + """", "ContentID: """ + cid + """" + EndOfLine.CRLF + "Content-disposition: inline; filename=""" + f.Name + """")

mail.Source = src

// Add the message to the SMTPSocket and send it
SendMailSocket.Messages.Add(mail)
SendMailSocket.SendMail
System.DebugLog("SendMail: Done")

You can do the parsing a litte better, but that should do it. If Xojo changes the way, the source is build, it could break in future.

Gabriele_Marchionni · July 5, 2024, 10:51pm

@Marius_Dieter_Noetzel I tried before to change source of message but Xojo change the source when send.

This is the source after modify and before to send:

Mime-Version: 1.0
Content-transfer-encoding: 8bit
Content-Type: multipart/mixed; boundary="0cm29e9m9jrb"

--0cm29e9m9jrb
Content-Type: multipart/alternative; boundary="36olz3a6ws0m"

--36olz3a6ws0m
Content-type: text/plain;

Title 1 of my email
Paragraph in the body
This is a test email. Let's try inserting html code with bold and also a link.


--36olz3a6ws0m
Content-type: text/html;

<!DOCTYPE html>
<html>
<head>
<title>Test email message with xojo</title>
<meta charset="utf-8">
</head>
<body>
<h1>Title 1 of my email</h1>
<p>Paragraph in the body</p>
<p>This is a test email. Let's try inserting html code with <strong>bold</strong> and also a <a href="https://xojo.com">link</a>.</p>
<p>
<img src="cid:part1.02080004.04000407@sample.com" alt="img_inline" width="16" height="16">
</p>
</body>
</html>


--36olz3a6ws0m--


--0cm29e9m9jrb
Content-Type: image/png; name="img_inline.png"; name*=utf-8''img_inline.png
Content-transfer-encoding: Base64
ContentID: "part1.02080004.04000407@sample.com"
Content-disposition: inline; filename="img_inline.png"; filename*=utf-8''img_inline.png

iVBORw0KGgoAAAANSUhEUgAAABAAAAAQCAYAAAAf8/9hAAAACXBIWXMAAAsTAAALEwEAmpwYAAAB
V0lEQVQ4jWNgQAPZ8zx1M+d5T8yY530lY57PFwgGsuf7TMiY462Drh4Ocid6sGfO95mWMd/7L5D+
jxXP8/4DxFNCV4WyYWgG2rQPp0YM7L0XxRCgE6cTrxmOJ8P9jNfZUAy05GLWfN8EIPsWzDtZC3y1
GUCBQ4TmK7lzPURBFgL5AXDx+d59QAHvqwT8eyNrvpcESHN9vT0LUNMGJPnLIAM+oYX0QyT+3dxZ
HjIgzcBAYwZqXoZm+CdUA+Z5d4EUp8/zSQdpzprjJY/Q7LMYi+s+oXgBqCgWPX3U19czAcNgPg4v
XkYJRFCqy5zrYw/X/Z+BEV8UA73UywBKnuAUhjDkY+Y8LyuQZqDrZuBLlelz/bTAFoGSJ5rkT6Dp
t/HGDjC/wF0KSpZAp+4hIRXuTptpzIoSWCBDQMkT2Ts4MtNEDM3IAJQ8QSkMFMJA+jMIQ9m9cD8j
AQCwK8QMzT+fqQAAAABJRU5ErkJggg==

--0cm29e9m9jrb--

And everything seems correct.

But when I actually send this is what arrives:

Mime-Version: 1.0
Content-transfer-encoding: 8bit
Content-Type: multipart/mixed; boundary="ulxokkrao35o"

--ulxokkrao35o
Content-Type: multipart/alternative; boundary="xkh2v4qbgvtm"

--xkh2v4qbgvtm
Content-type: text/plain;

Title 1 of my email
Paragraph in the body
This is a test email. Let's try inserting html code with bold and also a link.




--xkh2v4qbgvtm
Content-type: text/html;

<!DOCTYPE html>
<html>
<head>
<title>Test email message with xojo</title>
<meta charset="utf-8">
</head>
<body>
<h1>Title 1 of my email</h1>
<p>Paragraph in the body</p>
<p>This is a test email. Let's try inserting html code with <strong>bold</strong> and also a <a href="https://xojo.com">link</a>.</p>
<p>
<img src="cid:part1.02080004.04000407@sample.com" alt="img_inline" width="16" height="16">
</p>
</body>
</html>



--xkh2v4qbgvtm--
--ulxokkrao35o
Content-Type: image/png; name="img_inline.png"; name="img_inline.png"
Content-transfer-encoding: Base64
Content-disposition: attachment; filename="img_inline.png"; filename="img_inline.png"


--ulxokkrao35o
Content-Type: image/png; name="img_inline.png"; name="img_inline.png"
Content-transfer-encoding: Base64
Content-disposition: attachment; filename="img_inline.png"; filename="img_inline.png"


--ulxokkrao35o--

The boundary has also changed.

And that’s all I do. After changing the source I send immediately.

Dim src As String = eMess.Source
src = src.Replace("Content-disposition: attachment; filename=""" + fImg.Name + """", "ContentID: """ + cid + """" + EndOfLine.CRLF + "Content-disposition: inline; filename=""" + fImg.Name + """")
eMess.Source = src
oSMTP.Messages.Add(eMess)

Gabriele_Marchionni · July 5, 2024, 10:57pm

@TimStreater I’m trying to send a message with the image, not display it.
How did you send inline image messages? I tried but Xojo changed the source before sending it and the email arrived without an image.

TimStreater · July 6, 2024, 9:24am

What are you using to actually send the data?

As I said, I don’t use any Xojo email classes. I just send strings to the SSLsocket:

threadSocket.Write (imagelines(i) + app.NL)

where threadSocket is an SSLsocket, imagelines contains the lines of base64 data to be sent, and app.NL is the CR/LF string.

It looks to me like you are building the email parts (text part, html part, images parts) into a large piece of text, but then using the Xojo email classes to send it.

Gabriele_Marchionni · July 6, 2024, 11:01am

As I wrote in my first line of this post, I’m using Xojo 2024r2 Desktop, with components EmailMessage e SMTPSecureSocket.

The theme was precisely this, using the components provided by xojo to send messages.

And it seems that in the standard Xojo components there is no way to add inline images.

TimStreater · July 6, 2024, 12:39pm

Standard components of Xojo is what I am using. But not EmailMessage or SMTPSecureSocket.

Christian_Schmitz · July 6, 2024, 12:48pm

Do you use MBS Xojo Plugins?

You could use the CURLEMailMBS class for this.

For the inline graphics you use the AddAttachment method with InlineID to pass the ID, which you then use in the html with cid: URL to reference them.

John_Scanlan · September 3, 2026, 4:57am

I keep trying to do this, but I keep getting that it won’t work in gmail. (and no, I don’t use MBS because it’s really expensive for an amateur).

Any better ideas?

Beatrix_Willius · September 3, 2026, 9:33am

Please make a new topic with your code and the result.
